Download C51BY Specification
What's in the Box
1 X Cameras
1 X User Manual
Camera
|
Image Sensor2MP CMOS Image Sensor |
Video Resolution1920 (H) X 1080 (V) |
|
Signal SystemPAL/NTSC |
Frame RatePAL: 1080p@25 fps NTSC: 1080p@30 fps |
|
Lens3.6 mm |
Min. IlluminationColor: 0.02 Lux @(F1.2,AGC on); 0 Lux with IR on |
|
Angle of Viewhorizontal FOV: 76.9°, vertical FOV: 40.6°, |
Number of Infrared LEDs1 |
|
Night Vision DistanceUp to 100 ft/30 m |
DNR2D DNR |
|
Wide Dynamic RangeDWDR |
IR-Cut FilterYes |
|
Video OutputHD BNC X1 |
|
|
Image Sensor2MP CMOS Image Sensor |
|
Signal SystemPAL/NTSC |
|
Lens3.6 mm |
|
Angle of Viewhorizontal FOV: 76.9°, vertical FOV: 40.6°, |
|
Night Vision DistanceUp to 100 ft/30 m |
|
Wide Dynamic RangeDWDR |
|
Video OutputHD BNC X1 |
|
Video Resolution 1920 (H) X 1080 (V) |
|
Frame Rate PAL: 1080p@25 fps NTSC: 1080p@30 fps |
|
Min. Illumination Color: 0.02 Lux @(F1.2,AGC on); 0 Lux with IR on |
|
Number of Infrared LEDs 1 |
|
DNR 2D DNR |
|
IR-Cut Filter Yes |
General
|
HousingPlastic |
ColorWhite |
|
Operating PowerDC 12 V |
Operating Temperature-40 °F – 140 °F/-40 °C – 60 °C |
|
Indoor/OutdoorIndoor/Outdoor |
Weatherproof RatingIP67 |
|
Dimension (L X W X H)5.465 X 2.389 X 2.278"/138.8 X 60.9 X 57.9mm |
Weight0.32 lb./145 g |
|
HousingPlastic |
|
Operating PowerDC 12 V |
|
Indoor/OutdoorIndoor/Outdoor |
|
Dimension (L X W X H)5.465 X 2.389 X 2.278"/138.8 X 60.9 X 57.9mm |
|
Color White |
|
Operating Temperature -40 °F – 140 °F/-40 °C – 60 °C |
|
Weatherproof Rating IP67 |
|
Weight 0.32 lb./145 g |
